FC fast connector

Product Overview

FC fast connector description:Precise mechanical dimensionsLow insertion lossHigh repeatabilityHigh return lossFC fast connector Applicationprerequisite environmentDesktop connectivity for LAN environments distribution frameDirect Device Termination Repair/replacement requirements Equipment test lea

Product Model：FC fast connector

Update Time：2025-06-17

Fiber Type：Single-mode, Muti-mode

Fiber coreSimplex,duplex

Manufacturer Type：

Fiber Core Count：2-288 Cores

Outer Jacket：

Standard：

Port Type：Simplex,duplex

Polishing Type：UPC, APC

Adapter Type：SC,LC,FC,ST,E2000

Splitter Type：Insert Type/Box type/Mini PLC splitter

Connector Type：FC, ST, SC, LC

Inquiry Now

FC fast connectorDetailed Introduction

Online Message

FC fast connector(pic1)

FC fast connector description:

Precise mechanical dimensions
Low insertion loss
High repeatability
High return loss

FC fast connector Application

prerequisite environment
Desktop connectivity for LAN environments
distribution frame
Direct Device Termination
Repair/replacement requirements
Equipment test lead
FTTX

Specifications

Item	UPC		APC
Item	Φ0.125mm	Φ0.25mm	Φ0.125mm	Φ0.25mm
Radius of Curve(mm)	7~25	10~25	5~12	5~12
Return Loss(dB)	50	50	55	55
Apex Offset(um)	≤50
Fiber Height(nm)	-0.5
Polishing Angle(°)	8±0.3
Testing wavelength(nm)	1310&1550
Insertion Loss	≦0.3dB
Operating temperature	-40℃~ +80℃
Cable diameter	0.9mm, 2mm, 3mm
Service life	N＞1000
Dust Cap	LDPE
Connectors type	FC, ST, SC, LC
Polishing type	UPC, APC
Fiber type	Single-mode, Muti-mode
Port type	Simple, double
Application	drop cable/patch cords/pigtail

application

Fiber-optic-access-networks
CATV
Fiber-optic-communications
